Cupla rapida distribuitor SCV John Deere FASTER AL166181 AL200979 AL221083 AL112951 AL119348 3CFHF08212215F

Cupla rapida distribuitor SCV John Deere FASTER AL166181 AL200979 AL221083 AL112951 AL119348 3CFHF08212215F

Connection no 1 type - Thread
Connection no 1 type - Male
Connection no 1 thread diameter - M22
Connection no 1 thread pitch - 1.50 mm
Connection no 1 thread type - Metric
Connection no 1 thread type code - 21
Connection no 1 hex size - 32 mm
Body size - 12.5 mm
Connection 2, type - Quick coupling
Connection 2, type - male/female - Female
Connection 2, diameter - 42 mm
ISO standard 7241-A 9974-2
Flow rate at 2 bar - 70 l/min
Material - Steel
Working pressure - 250 BAR
Max working pressure - 250 BAR
Max working temperature - 114 °C
Min. working temperature -  -25 °C
Quick connection locking type - Radial balls
Quick connection working type - Push to connect
Quick disconnection working type - Pull to disconnect
Seal material - Polyurethane
Valve type - Poppet



Se potriveste pe urmatoarele modele:

5080R, 5080RN , 5090R, 5090RN , 5100R, 5100RN , 5620, 5720, 5820 , 6010, 6110, 6210 , 6020, 6120, 6220 , 6090MC , 6090RC , 6100, 6200 , 6100MC , 6100RC , 6105M , 6105R , 6110J , 6110MC , 6110RC , 6115M , 6115R , 6125J , 6125M , 6125R , 6130 , 6130J , 6130M , 6130R , 6135M , 6140M , 6140R , 6145J , 6145M , 6150M , 6150R , 6150R, 6150RH , 6155M , 6165J , 6170M , 6170R , 6185J , 6190R , 6195M , 6205J , 6210J , 6210R , 6215, 6415 , 6230 Premium , 6230 , 6300, 6400 , 6310, 6410 , 6320, 6420, 6420S , 6330 Premium , 6330 , 6405 , 6415 , 6425 , 6430 Premium , 6430 , 6506, 6600 , 6510, 6610 , 6520, 6620 , 6530 Premium , 6530 , 6534 Premium , 6534 , 6605 , 6615, 6715 , 6615 , 6630 Premium , 6630 , 6800, 6900 , 6810, 6910, 6910S , 6820, 6920, 6920S , 6830 Premium , 6830 , 6930 Premium , 6930 , 6J-1654 , 6J-1704 , 6J-1854 , 6J-1904 , 6J-2054 , 6J-2104 , 7130 Premium , 7130 , 7195J , 7210J , 7230 Premium , 7230 , 7330 Premium , 7330 , 7430 E Premium , 7430 Premium , 7530 E Premium , 7530 Premium , SE6010, SE6110, SE6210, SE6310, SE6410 , SE6020, SE6120, SE6220 , SE6100, SE6200, SE6300, SE6400 , SE6320, SE6420, SE6520, SE6620 , SE6510, SE6610 , SE6920
